30" Under-Cabinet / Wall Mount Core Series | JQG7522

$699.00
$899.00
$699.00
84 Reviews

Slant Vent Series 30 in. 850 CFM Under Cabinet or Wall Mounted Range Hood in Onyx Black

  • 30" wall-mount/under-cabinet range hood
  • Black tempered glass
  • Max EQUIV. CFM: 850*
  • 39dB Min. Noise Level
  • Slant design for exhaust extraction
  • Close proximity to cooking surface and smoke
  • 90° Fixed Open Capture Shield
  • Covers 6ft² of Cooking Area (5-6 Burners)
  • Dual AC Motors
  • 95% Grease Separation Rate 98% Odor Elimination Rate

*Please note: The actual product color may vary slightly from the images shown due to differences in lighting, screen settings, and product finishes.

    FOTILE America

      Add FOTILE Extended Limited Warranty:

      1 Year

      $49.99

      2 Years

      $109.99

      3 Years

      $179.99

      Learn More:


      Download spec sheet

      Download 30” Slant Vent Series Installation Template

      Become a Dealer

      JQG02 Series | 30" Range Hood - FOTILE

      30" Under-Cabinet / Wall Mount Core Series | JQG7522

      $899.00 $699.00

      30" Under-Cabinet / Wall Mount Core Series | JQG7522

      $899.00 $699.00

      WhisPower System

      Due to our WhisPower Technology, FOTILE’s JQG02 wall-mounted range hood is able to capture a higher CFM than actually published by achieving the Venturi effect created with our Capture Shield Technology. Air speed and power are increased as we capture smoke and grease in the Golden Collection Zone and pass it through our centrifugal WhisPower motors.

      Extra-wide Fume Inlet ensures even suction pressure at every angle

      90-degree Fixed Open Fume Capture Shield prevents smoke from spreading effectively and protects you against harm.

      Extra-wide Fume

      6 sq. Ft. Super-large Coverage Area easily covers all the burners on your cooktop.


      Super-large Coverage Area easily covers all the burners on your cooktop

      30-inch Extra-wide Fume Inlet ensures even suction pressure in our wall mount range hoods at every angle. 6 sq. ft. Super-large Coverage Area easily covers all the burners on your cooktop.

      More Features

      7502-dual motor.jpg__PID:87af4e08-cc83-4e05-8894-48d75976c0e0

      Double Centrifugal Fans ensure strong power and fluent extraction.

      Super Quiet Operation JQG02.jpg__PID:4e08cc83-be05-4894-88d7-5976c0e0e3fa

      Super Quiet Operation: Lowest speed has 39dB noise level; Mid speed has 49.2dB; High speed has 54.3dB.

      明亮灯光 拼合.jpg__PID:cc83be05-0894-48d7-9976-c0e0e3fa6da4

      Powerful Lights light up the whole cooking area below the range and help you see the color of the food you are cooking.

      Person holding a large capacity grease tray for the JQG02 Series.

      Large Grease Tray with more volume decreases the frequency of cleaning.

      Person folding the dishwasher safe oil filter for the JQG02 Series.

      Folding Oil Filter is dishwasher safe.

      7522(6).jpg__PID:be050894-48d7-4976-80e0-e3fa6da4e373

      Fixed Open Fume Capture Shield reduces waiting time, and can be used when it's opened.

      Specifications

      ModelJQG7522
      CertificationETL, HVI, CEC
      Product Dimensions(W x D x H)29 7/8" x 18 7/16" x 17 7/16"
      Power Supply120V/60HZ
      Max Static Pressure(Pa)400Pa
      Speed Setting3

      USER MANUAL

      DOWNLOAD

      SPEC SHEET

      DOWNLOAD

      installation guide

      DOWNLOAD

      brochure

      DOWNLOAD

      3D Design File

      DOWNLOAD

      ACCESSORIES Lists

      DOWNLOAD

      Range Hoods Sheet Dimension

      DOWNLOAD

      Warranty Document

      DOWNLOAD

      schedule
      service

      Troubleshooting

      PRODUCT WARRANTIES & REGISTRATION

      ASK A
      QUESTION

      FOTILE WARRANTY POLICY For range hood purchases

      Fotile is offering five years limited warranty on range hood products. Life time limited warranty on motors
      From your purchase date, TWO (2) YEARS FULL WARRANTY ON ALL FOTILE RANGE HOOD PRODUCTS AND PARTS AND THREE (3) YEARS LIMITED WARRANTY ON ALL PARTS OF FOTILE RANGE HOOD PRODUCTS*
